Plastic Pallets

L3®

The L3® is the ultimate long-lasting plastic pallet for heavy-duty intralogistics applications. It impresses with a high load-bearing capacity of up to 2,000kg in high rack warehouses and remains maintenance-free, even with increasing trip rates. The consistently high quality of the durable and reusable pallet makes it an ideal economical choice. The reusable plastic pallet is equipped with Palgrip® anti-slip strips on the top deck as a standard feature, offering a secure hold even at an inclined position or in damp conditions. Thanks to evenly closed Palgrip® anti-slip runners, the L3 runs absolutely smoothly on all standard conveyor technology systems.


Characteristics:

  • Available with 3 runners
  • Very high load-bearing capacity for heavy-duty applications
  • Corrosion-protected reinforcement profiles, for a load-bearing capacity of up to 2,000kg in high rack
  • Welded runners for a high standard of hygiene and smooth running on roller conveyors
  • Chamfered edges on both sides of all runners for optimal handling with forklift trucks
  • Palgrip® anti-slip strips on the top deck
  • Palgrip® anti-slip coating under the runners


Options:

  • Rims: without, 5mm
  • RFID transponder
Product enquiry
L3® | Data sheet (PDF)
Art. no.
Weight (kg)
Load Capacity (kg) Static *3
Load capacity (kg) Dynamic *3
Load Capacity (kg) In Racking System *3
Colour
Runners
ESD
Reinforcement profiles
Central box retainers
Rim (mm)
Full-surface Palgrip® anti-slip top deck
Palgrip® anti-slip strips on the top deck
Anti-slip plugs on the underside of the deck
Palgrip® anti-slip runners
Palgrip® anti-slip pads on the top deck
Palgrip®-Antirutschclips
Amount
83341881 26 kg 7,500 kg 2,000 kg 2,000 kg light grey / light blue 3, welded 5 5 mm
83349881 26 kg 7,500 kg 2,000 kg 2,000 kg basalt grey / light blue 3, welded 5 5 mm
  • Technical information *1
    Internal Dimensions (mm) 1200 x 1000 x 160
    Temperature stability -30 °C to +40 °C, briefly up to +90 °C
    Art. no.
    Weight (kg)
    Load Capacity (kg) Static *3
    Load capacity (kg) Dynamic *3
    Load Capacity (kg) In Racking System *3
    Colour
    Runners
    ESD
    Reinforcement profiles
    Central box retainers
    Rim (mm)
    Full-surface Palgrip® anti-slip top deck
    Palgrip® anti-slip strips on the top deck
    Anti-slip plugs on the underside of the deck
    Palgrip® anti-slip runners
    Palgrip® anti-slip pads on the top deck
    Palgrip®-Antirutschclips
    83341881 26 kg 7,500 kg 2,000 kg 2,000 kg light grey / light blue 3, welded 5 5 mm
    83349881 26 kg 7,500 kg 2,000 kg 2,000 kg basalt grey / light blue 3, welded 5 5 mm

    *1:

    All technical data include characteristic features, which have been tested under specially defined conditions. Varying data may result from different conditions of usage such as loading method, prevailing temperature and length of storage time. All data and specified information are subject to change without notice. Our service team is pleased to be at your disposal to check the special requirements of your individual application.

    *2:

    Our service team is pleased to be at your disposal if you require exact information about material compositions.

    *3:

    Static load: resistance to pressure on a flat ground surface and an evenly distributed load at a room temperature of approx. 20 °C.

    Dynamic load: on a forklift with an evenly distributed load at a room temperature of approx. 20 °C.

    In racking system: evenly distributed load (sacks) along the longitudinal sides. Resting on two supports for over 100 h at a room temperature of approx. 20°C.

  • Technical drawings
  • Loading quantities (Pcs / Approximate amount)
    Container Container 20': 141 Pcs.
    Container 40': 300 Pcs.
    Container 40' High Cube: 340 Pcs.
    Conventional trailer 45’ high cube container: 416 Pcs.
    Truck MEGA Trailer: 468 Pcs.
    Jumbo: 504-540 Pcs.
  • Labeling options
    Customised printing and numbering available on request depending on quantity. Position upon consultation.
  • Technical drawings
