TC1 ECO

The completely closed TC1 recycled Euro pallet combines high load bearing capacity for heavy duties with an excellent price/performance ratio.

Characteristics:

  • Patended welding seam geometry of top and bottom deck ensures highest impact resistance, breaking strength and solid wall thickness
  • Excellent bending strength, ideal for roller conveyors and automated high rack systems
  • Ideal for transportation and storage of bagged goods
  • All runners have chamfered edges on both sides for ideal use with fork lift trucks

Option:

  • Corrosion-protected reinforcement profiles, for load capacities of up to 1.750 kg in high rack
  • Rim options: Without, 7 mm, 22 mm
  • Integration of RFID transponders
Watch Video
Data sheet (PDF)

TC1 ECO | Data sheet (PDF)

Art. No.
Weight (kg)
Load capacity (kg) Static *2
Load capacity (kg) Dynamic *2
Load capacity (kg) High rack *2
Colour
Runners
RFID Transponder
Reinforcement profiles
Central box retainers (mm)
Rims (mm)
Anti-slip
87065201 18 kg 7500 kg 1250 kg 1000 kg black 3, unwelded 7 mm
Product enquiry

TC1 ECO | Data sheet (PDF)

Art. No.
Weight (kg)
Load capacity (kg) Static *2
Load capacity (kg) Dynamic *2
Load capacity (kg) High rack *2
Colour
Runners
RFID Transponder
Reinforcement profiles
Central box retainers (mm)
Rims (mm)
Anti-slip
87065201 18 kg 7500 kg 1250 kg 1000 kg black 3, unwelded 7 mm

Any questions?

Telephone: +49 5245 43-0

E-Mail: info(at)craemer.com

  • Technical data*1
    Dimensions L×W×H (mm) 1200 x 800 x 160
    Material PE
    Temperature stability -30 °C to +40 °C, briefly up to +90 °C
    Art. No.
    Weight (kg)
    Load capacity (kg) Static *2
    Load capacity (kg) Dynamic *2
    Load capacity (kg) High rack *2
    Colour
    Runners
    RFID Transponder
    Reinforcement profiles
    Central box retainers (mm)
    Rims (mm)
    Anti-slip
    87065201 18 kg 7500 kg 1250 kg 1000 kg black 3, unwelded 7 mm

    *1:

    All technical data include characteristic features, which have been tested under specially defined conditions. Varying data may result from different conditions of usage such as loading method, prevailing temperature and length of storage time. All data and specified information are subject to change without notice. Our service team is pleased to be at your disposal to check the special requirements of your individual application.

    *2:

    Our service team is pleased to be at your disposal if you require exact information about material compositions.

    *3:

    Static load: resistance to pressure on a flat ground surface and an evenly distributed load at a room temperature of approx. 20 °C.

    Dynamic load : on a forklift with an evenly distributed load at a room temperature of approx. 20 °C.

    In racking system: evenly distributed load (sacks) along the longitudinal sides. Resting on two supports for over 100 h at a room temperature of approx. 20°C.

  • Technical drawings
  • Loading quantities (pcs/approx.)
    Container 20' Container: 192 St.
    40' Container: 390 St.
    40' Container high cube: 440 St.
    Conventional trailer 45’ high cube container: 495 St.
    Truck MEGA-Trailer (13,60 × 2,45 × 3,00 m): 612 St.
    Jumbo: 684 St.
  • Labelling options
    Customised printing and numbering available on request depending on quantity. Position upon consultation.
  • Technical data sheets

    Art. No.: 87065201
    Colour: black
    Runners: 3, unwelded
    Rims (mm): 7 mm
